Industrial Type 3600-8000pcs/H 8-10inch Tortilla Production Line

Brand Name : sss

Model Number : customized

Certification : CE

Place of Origin : China

MOQ : 1

Price : 80000

Payment Terms : L/C, T/T

Supply Ability : 10set/y

Delivery Time : 60days

Packaging Details : standard exporting package

Contact Now

Industrial Type 3600-8000pcs/H 8-10inch Tortilla Production Line

Main feature & parameter

1. Humanized design and compact structure;
2. Microcomputer control, convenient operation;
3. Wide range of applications, and can make products of different sizes;
4. Flexible collocation, can be freely customized according to customer needs;
5. It is safe and reliable, and food contact parts are made of high-quality stainless steel and food-grade polymer materials.

Structure

The main operating steps of this machine are: flour mixing,divider,dough proofing,
dough pressing, baking, cooling, stacking and packing.

Machine Name	Size(mm)	Power	Description
Dough Conveyor	910X650X1050	0.24KW	It can convey 2-3 rows dough ball with adjustable distance.
Presser	3200X1390X1915	34.5KW	Cycles in a minute: 20 - 35 times? Capacity for each size: 3600 pcs/hour for 25cm (10”) Frame: stainless steel, heavy duty Working temperature: 0 - 300℃ Servo tracking continuous pressing Teflon belt runs at constant speed Size of press heating plate: 65x65cm 4 pcs /time for 25cm (10") The pressing time is closely related according to the size of the tortilla and the temperature of heating plate. The temperature can be controlled separately, and the temperature error is ±3℃. The machine frame is made of stainless steel, and the pressing area is heavy duty steel plate with painting treatment
Oven	5150X1480X1350	2.2KW	The oven has three layers in total. The upper two layers are stainless steel heating chain plate, and the lowest layer is stainless steel conveyor mesh belt. Each layer of heating chain plate is equipped with 4 sets of gas heating system, which can be controlled separately. The heating chain plate and bottom mesh belt can be adjusted to meet the baking time which is required for different tortillas. It is equipped with electronic ignition system, flame detection and alarm system. The machine frame is made of stainless steel. Isolation system: critical parts covered with stone wool Frame : stainless steel, heavy duty Drive system : by motor Continuous system: yes Baking time: 30 - 90 seconds
Cooling line	8700X1080X1500	1.5KW	5-layer and 6-metre high cooling system, each layer can individually control the conveying speed, the top is equipped with cooling fan.
Electric cabinet	700X550X1800	0.15KW
Chiller	840X620X1060	3.6KW
Counter & Stacker	3100X1240X1010	0.74KW	Multiple cylinders are combined with the detection and counting system to control the number of stacked tortillas, the stacked quantity can be adjusted.

Industrial Type 3600-8000pcs/H 8-10inch Tortilla Production Line

Industrial Type 3600-8000pcs/H 8-10inch Tortilla Production Line Images
